RW-M6.1-B (EU, AU)
- 4.5 inch HD Screen
- Android 4.4 KitKat OS
- 1.4 GHz Quad Core™ Processor
- 20 MP front Camera
Chemistry & Capacity: LiFePO4 battery, 120Ah capacity
Scalability & Energy: Up to 32 units in parallel (196kWh total), 6.14kWh usable energy per unit
Performance: 3.07kW rated DC power, charge/discharge currents (recommend 60A, max 100A, peak 150A), 100% depth of discharge
Durability & Warranty: ≥6000 cycles, 10-year warranty, 20MWh throughput
Installation & Design: Wall/floor-mounted, IP65 enclosure, wide operating temp range (-20℃ to 55℃)
Certification: UN38.3, IEC62619, CE, etc
Technical Specifications
Model RW-M6.1-B
Battery Chemistry LiFePO4
Capacity 120Ah
Scalability Max.32 pcs in parallel
Nominal Voltage 51.2V
Operating Voltage 43.2V~57.6V
Energy 6.14kWh
Weight Approximate 58kg
Dimension（W×H×D） 510×740×145 mm
